Slug Detector DUCIS SD-822/ SD-824

DESCRIPTION

High resolution bottom dead center detector die high detector SD-822/824:
SD-822/824 Die height detector are highly accurate bootom dead center detector which achieved sub micron resolution by using the latest analogue/digital technologies.SD-822/824 are designed to enable more wide area detection by high resolution of 0.1Um and the useful functoin by the experience of many years.

Features

SD-822-One basic unit, Dual output device (Dual Port)
SD-824-One basic unit,  four output device (four  Ports)

1.Sensor operation setup distance: Location(A) from 0.8mm to 1.2mm, please press MONITOR ON/OFF switch thereafter the red light lights up.Then press setup switch thereafter “Hi” displayed. Move the iron block of the sensor head, it can be adjusted to 0.8mm~1.2mm as operation distance.(Meaning 0.8mm to 1.2mm). Press MONITOR ON/OFF switch again after set-up process,the Green light lights up.
2.Operation of monitoring value setup: Accuracy range set up from ±0.1μm~±99.9μm,depends on your exact accuracy requirement.
3.While stamping die starts running, the first six times displaying digits meaning the average of the die-height testing.(It will be recalculated  while stamping machine power off or the sensor line out of the basic unit and re-plug-in),please press monitor MONITOR ON/OFF switch thereafter the green light lights up.
4.This product can be choose set up in effective or ineffective.The lights is red when the set up is off.The lights is green when the set up is on.
5.This product provides precision set-up value as 0.1μm, it is selectable against different accurate toolings.
6.Options available for Error-Carry-On, Missing material (by Electro-Eyes sensor) and Material Jammed (By sensoring Bar).
